1 Hardware Overview 1.8 Power Supply
1-22 Satellite Pro M10 Series Maintenance Manual (960-431)
The power supply output rating is specified in Table 1-6.
Table 1-6 Power supply board output rating
Power supplied Yes/No
Use Name
Voltage
(V)
Stand by Power off No battery
CPU (core) PPV 1.3 No No No
CPU (bus), MCH-M, ICH4-M PTV 1.075 No No No
VGAC BGV 1.35 Yes No No
HDD, Keyboard, Touch Pad,
Accupoint, Mini PCI, Bluetooth, FL
P5V 5.0 No No No
ICH4-M, FWH, Clock Generator,
ADM1032AR, SD Card, Mini PCI,
Super I/O, FIR, IEEE 1394, LCD,
CODEC
P3V 3.3 No No No
MCH-M, ICH4-M 1R8-P1V 1.81 No No No
MCH-M, ICH4-M, VGAC 1R5-P1V 1.5 No No No
SO-DIMM, MCH-M 1R25-P1V 1.25 Yes No No
OZ168 S5V 5.0 Yes Yes No
ICH4-M, EC/KBC S3V 3.3 Yes Yes No
ICH4-M 1R5-S1V 1.5 Yes Yes No
VGAC, PC Card B5V 5.0 Yes No No
YEBISU3S, VGAC, PC Card,
Mini PCI, MDC, Serial
B3V 3.3 Yes No No
MCH-M, VGAC, SO-DIMM, VRAM 2R5-B2V 2.51 Yes No No
CODEC, Ext. Microphone,
Int. Microphone, Headphones,
USB, Slim Select Bay
E5V 5.0 Yes No* No
ICH4-M, 82562ET E3V 3.3 Yes No* No
PSC MCV 5.0 Yes Yes No
ICH4-M (RTC) R3V 2.0 - 3.6 Yes Yes Yes
*: These items are supplied with power if the wake-up function is enabled.
