C HAPTER 12: ADVANCED ADMINISTRATION 209
Figure 263 Edit Status Console Config
3. Click Save at the bottom of the screen or press the TAB key and press Enter once Save is
highlighted. Press ^Q or ^C to exit.
Editing Network Interfaces Configuration (Network Interfaces)
In Network Interface Configuration, you can perform initial setup tasks such as setting the
hostname and IP address of the CC-SG. Click with the mouse or use the TAB,
↓↑ keys to
navigate and press the Enter key to select a value.
1. To edit network interface information, click Operation, Network Interfaces, then Network
Interface Config.
Figure 264 Selecting Network Interface Configuration
Port Number
for Diagnostic
Console
