Web OS 10.0 Application Guide
Chapter 14: Virtual Private Network Load Balancing
n
361
212777-A, February 2002
6.
Configure Virtual Router Redundancy Protocol (VRRP) for virtual routers 1 and 2.
7.
Enable SLB.
8.
Configure real servers for health checking VPN devices.
9.
Enable the real server group.
10.
Enable RTS on the necessary ports.
>> # /cfg/vrrp/on
>> Virtual Router Redundancy Protocol# vr 1
>> VRRP Virtual Router 1# ena
>> VRRP Virtual Router 1# vrid 1
>> VRRP Virtual Router 1# if 1
>> VRRP Virtual Router 1# addr 30.0.0.50
>> VRRP Virtual Router 1# share dis
>> VRRP Virtual Router 1# track/vrs ena
>> VRRP Virtual Router 1 Priority Tracking# /cfg/vrrp/vr 2
>> VRRP Virtual Router 2# ena
>> VRRP Virtual Router 2# vrid 2
>> VRRP Virtual Router 2# if 2
>> VRRP Virtual Router 2# addr 20.0.0.1
>> VRRP Virtual Router 2# share dis
>> VRRP Virtual Router 2# track/ports ena
>> VRRP Virtual Router 2 Priority Tracking# /cfg/slb/on
>> Layer 4# /cfg/slb/real 1/ena/rip 10.0.0.10
>> Real server 1# ../real 2/ena/rip 10.0.0.11
>> Real server 2# ../real 3/ena/rip 10.0.0.20
>> Real server 3# ../real 4/ena/rip 10.0.0.21
>> Real server 4# ../group 1
>> Real server group 1# metric hash
>> Real server group 1# add 1/add 2/add 3/add 4
>> Real server group 1# ../port 7/rts ena
>> SLB port 7# ../port 8/rts ena
