Nortel Networks WEB OS 212777 User Manual
Page 340

Web OS 10.0 Application Guide
340
n
Chapter 13: Firewall Load Balancing
212777-A, February 2002
3.
Configure VRRP on the primary dirty-side Web switch.
VRRP in this example requires two virtual routers–one for the subnet attached to the routers,
and one for the subnet attached to the firewalls.
4.
Configure the VRRP peer on the primary dirty-side Web switch.
5.
Apply and save your configuration changes.
6.
Synchronize primary and secondary dirty-side Web switches.
>> # /cfg/vrrp
>> # on
>> # vr 1
>> # vrid 1
(Configure virtual router 1)
>> # addr 195.1.1.9
(For the subnet attached to the routers)
>> # if 1
>> # prio 101
>> # share dis
>> # ena
>> # track
>> # ifs ena
>> # ports ena
>> # /cfg/vrrp/vr 2
>> # vrid 2
(Configure virtual router 2)
>> # addr 10.10.2.9
(For the subnet attached to the firewall)
>> # if 2
>> # prio 101
>> # share dis
>> # ena
>> # track
>> # ifs ena
>> # ports ena
>> # /cfg/slb/sync
>> # prios d
>> # peer 1
>> # ena
>> # addr 195.1.1.11
>> # apply
>> # save
>> # /oper/slb/sync
