Web OS 10.0 Application Guide
34
n
Chapter 1: Basic IP Routing
212777-A, February 2002
Each time you add a port to a VLAN, you may get the following prompt:
Enter
y
to set the default Port VLAN ID (PVID) for the port.
3.
Add each IP interface to the appropriate VLAN.
Now that the ports are separated into three VLANs, the IP interface for each subnet must be
placed in the appropriate VLAN. From
, the settings are made as follows:
4.
Apply and verify the configuration.
Examine the resulting information. If any settings are incorrect, make the appropriate changes.
5.
Save your new configuration changes.
Port 4 is untagged and VLAN 2 is not a configured PVID for port 4.
Would you like to change all PVIDS for port 4 to VLAN 2 [y n]?
>> VLAN 3# /cfg/ip/if 1
(Select IP interface 1 for def. routers)
>> IP Interface 1# vlan 2
(Set to VLAN 2)
>> IP Interface 1# ../if 2
(Select IP interface 2 for first floor)
>> IP Interface 2# vlan 1
(Set to VLAN 1)
>> IP Interface 2# ../if 3
(Select IP interface 3 for second floor)
>> IP Interface 3# vlan 1
(Set to VLAN 1)
>> IP Interface 3# ../if 4
(Select IP interface 4 for third floor)
>> IP Interface 4# vlan 1
(Set to VLAN 1)
>> IP Interface 4# ../if 5
(Select IP interface 5 for servers)
>> IP Interface 5# vlan 3
(Set to VLAN 3)
>> IP Interface 5# apply
(Make your changes active)
>> IP Interface 5# /info/vlan
(View current VLAN information)
>> Information# port
(View current port information)
>> Information# save
(Save for restore after reboot)
