2 • Meet the DM500™ and DM550™ Digital Mailing System
Connecting
the IntelliLink ®
Control Center to
a Remote Phone
Line
This figure shows where you connect the AC adapter to the IntelliLink ®
Control Center after it has been removed from the mailing machine and
moved to a remote analog phone line. For both internal and external mo-
dems, use the 26 AWG telephone cord included with the modem to con-
nect to the phone line.
External USB
Modem Cable
for PCN 1CXX
only
External Modem
AC Adapter plugged
into IntelliLink
® Control
Center
Telephone Cord for
Analog Line
(26 AWG)
Internal analog line for
PCN 1DXX only
