SV61436 Rev. B C-5
DM500™ and DM550™ Digital Mailing System Operating Guide
Specifications
continued
Mailing Materials:
Envelope Dimensions (refer to envelope measurement figure on next
page)
Minimum
3 in. x 5 in. (76.2 mm x 127 mm) postcard size.
Maximum 10 in. x 13 in. (254 mm x 330 mm) in landscape orientation. C5
envelopes can be processed when in portrait orientation.
Envelope Flap Depth (refer to envelope measurement figure)
Minimum
1 in. (25.4 mm)
Maximum 3 in. (76.2 mm)
Envelope Thickness
Minimum
0.007 in. (0.18 mm)
Maximum 5/8 in. (15.9 mm)
Acceptable Envelope Materials Include
• Standard envelope paper
• Self-mailers
• Tri-fold mail
• Pre-sealed envelopes
Envelope Flap Profiles
• Commercial (square and baronial)
• Executive
• Monarch
Weight of the piece of mail
5 or 10 lbs. maximum for each piece (depending on capacity of optional scale)
1 lb. (16 oz). for systems with optional WOW™ module
Tape Roll Width
Either 4 in. (102 mm) or 5 inches (127 mm)
