Testing
7-5 7112-A2-GB20-20 March 1998
2. To manually stop the test, verify that the cursor is positioned at the Stop
command and press Enter.
496-15076
CSU DSU
Network
Interface
ALL 1s
PLB
DTE
Payload Loopback cannot be started when any other loopback or Send Pattern
test is already active on the network interface.
Repeater Loopback
Repeater Loopback (RLB) loops the signal being sent from the data port back to
the data port. Framing CRCs and BPVs are corrected.
"
Procedure
To run a Repeater loopback:
1. Position the cursor at the Start command next to Repeater Loopback on the
Network Tests screen and press Enter.
2. To manually stop the test, verify that the cursor is positioned at the Stop
command and press Enter.
496-15077
CSU DSU
Network
Interface RLB
DTE
ALL 1s
Repeater Loopback cannot be started when any of the following tests are already
active:
H
Data Terminal Loopback
H
Data Channel Loopback
H
Payload Loopback.
