Monitoring the DSU/CSU
6-16 7112-A2-GB20-20 March 1998
Table 6-6 describes the fields on the Management Protocol Statistics screen.
Table 6-6. Management Protocol Statistics Screen Contents
Label What the Field Indicates
Datagrams Transmitted The number of datagrams successfully transmitted at each
protocol layer.
Datagrams Received The number of datagrams successfully received at each
protocol layer.
Format Errors The number of protocol packets that contained errors.
Invalid Address The number of protocol packets that contained invalid
addresses.
Unknown Protocol The number of datagrams that were lost due to unknown
protocols.
Dropped Due To No
Route The number of datagrams that were lost due to no route.
All counts show the number of occurrences since the last reset of the counters.
