Paradyne 7112 - Manual (Page 101)

Worksheets
B-5 7112-A2-GB20-20 March 1998
SNMP
Configuration Option Settings (default in Bold)
General SNMP Management
SNMP Management Enable, Disable
Community Name 1 ASCII Text, Public
Name 1 Access Read, Read/Write
Community Name 2 ASCII Text
Name 2 Access Read, Read/Write
SNMP NMS Security
NMS IP Validation Enable, Disable
Number of Managers 1, 2, 3, 4, 5, 6, 7, 8, 9, 10
NMS n IP Address 000.000.000.000 – 255.255.255.255
(first byte cannot be 127)
Access Level Read, Read/Write
SNMP Traps
SNMP Traps Enable, Disable
Number of Trap Managers 1, 2, 3, 4, 5, 6
Trap Manager n IP Address 000.000.000.000 – 255.255.255.255
Trap Manager n Destination None, Ethernet, FDL
General Traps Disable, Warm, AuthFail, Both
Enterprise Specific Traps Enable, Disable
Link Traps Disable, Up, Down, Both
Link Trap Interfaces Network, Port, Both
