DTE V.35 Connector
The following table provides the pin assignments for the 34-position
V.35 connector to the DTE.
Signal
ITU
CT#
Direction
34-Pin
Socket
Connector
Signal Ground/Common 102 — B
Request to Send ( RTS ) 105 To DSU/CSU (In) C
Clear to Send ( CTS ) 106 From DSU/CSU
(Out) D
Data Set Ready ( DSR ) 107 From DSU/CSU
(Out) E
Received Line Signal Detector
( RLSD or LSD ) 109 From DSU/CSU
(Out) F
Data Terminal Ready ( DTR ) 108/1, /2 To DSU/CSU (In) H
Remote Loopback ( RL ) 140 To DSU/CSU (In) N
Local Loopback ( LL ) 141 To DSU/CSU (In) L
Transmitted Data ( TXD ) 103 To DSU/CSU (In) P ( A )
S ( B )
Received Data ( RXD ) 104 From DSU/CSU
(Out) R ( A )
T ( B )
Transmitter Signal Element Timing —
DTE Source ( XTXC or TT ) 113 To DSU/CSU (In) U ( A )
W ( B )
Receiver Signal Element Timing —
DCE Source ( RXC ) 115 From DSU/CSU
(Out) V ( A )
X ( B )
Transmitter Signal Element Timing —
DCE Source ( TXC ) 114 From DSU/CSU
(Out) Y ( A )
AA ( B )
Test Mode Indicator ( TM ) 142 From DSU/CSU
(Out) NN
