15.5.16
MMC_RES FIFO
MMC_RES FIFO, shown in
, contains the response after a command. It is 16 bits wide
by eight entries.The RES FIFO does not contain the 7-bit CRC for the response. The status for
CRC checking and response time-out status is in the status register, MMC_STAT.
The first half-word read from the response FIFO is the most significant half-word of the received
response.
This is a read-only register. Ignore reads from reserved bits.
15.5.17
MMC_RXFIFO FIFO
, consists of two dual FIFOs, where each FIFO is eight bits
wide by 32 entries deep. This FIFO holds the data read from a card. It is a read only FIFO to the
software, and is read on 8-bit boundaries. The eight bits of data are read on a 32-bit boundary and
occupying the least significant byte lane (7:0).
This is a read-only register. Ignore reads from reserved bits.
Table 15-21. MMC_RES, FIFO Entry
Physical Address
0x4110_003c
MMC_RES FIFO Entry
MultiMediaCard Controller
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9
8
7
6
5
4
3
2
1
0
reserved
RESPONSE_DATA
Reset 0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
Bits
Name
Description
31:16
—
reserved
15:0
RESPONSE_
DATA
Two bytes of response data
Table 15-22. MMC_RXFIFO, FIFO Entry
Physical Address
0x4110_0040
MMC_RXFIFO Entry
MultiMediaCard Controller
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9
8
7
6
5
4
3
2
1
0
reserved
READ_DATA
Reset 0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
x
x
x
x
x
x
x
x
Bits
Name
Description
31:8
—
reserved
7:0
READ_DATA One byte of read data
