DTMX5000 MIB File DTMX5000 IP Gateway
4–18 Rev. 1
4.2.4 Multicast Channel Parameters
Multicast parameters consist of the following:
•
IP Address of the Multicast Channel
•
Group
•
SID
•
Min Rate
•
Max Rate
4.2.4.1 IP Address of the Multicast Channel
MIB Object: cbMulticastIP
OID: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).
efdata(6247).spectracast(3).DTMX5000(1).cbConfig(2).
cbConfigMulticastTable(6).
cbMulticastTable(1).cbMulticastEntry(1).cbMulticastIP(1)
Description: IP address of the multicast channel.
Data Types: INTEGER
Access: Read-write
4.2.4.2 Group
MIB Object: cbMulticastGroup
OID: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).
efdata(6247).spectracast(3).DTMX5000(1).cbConfig(2).
cbConfigMulticastTable(6).
cbMulticastTable(1).cbMulticastEntry(1).cbMulticastGroup(2)
Description: The group to which the multicast user belongs.
Data Types: INTEGER
Access: Read-write
4.2.4.3 SID
MIB Object: cbMulticastSID
OID: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).
efdata(6247).spectracast(3).DTMX5000(1).cbConfig(2).
cbConfigMulticastTable(6).
cbMulticastTable(1).cbMulticastEntry(1).cbMulticastSID(3)
Description: The group to which the multicast channel resides.
Data Types: INTEGER
Access: Read-write
