DTMX5000 IP Gateway Specifications
Rev. 1 A–5
A.4 Parallel Output Pin Assignment
Table A-2 provides pin assignments for the Gateway's DB25 output connector.
Table A-2. Parallel Output Pin Assignment
PIN Number Pin Name Type Description
1 Clock A Output Output clock signal
2 GND Output
3 Data 7A Output
4 Data 6A Output
5 Data 5A Output
6 Data 4A Output
7 Data 3A Output
8 Data 2A Output
9 Data 1A Output
10 Data 0A Output
11 DVALID A Output Data valid signal A
12 SYNC A Output SYNC signal A
13 Cable Shield Output
14 Clock B Output Output clock signal
15 Board GND Output
16 Data 7B Output
17 Data 6B Output
18 Data 5B Output
19 Data 4B Output
20 Data 3B Output
21 Data 2B Output
22 Data 1B Output
23 Data 0B Output
24 DVALID B Output Data valid signal B
25 SYNC B Output SYNC signal B
Note: All signals are outputs. The Gateway generates clock signals.
