Comtech EF Data DTMX5000 SpectraCast - Manual (Page 104)

DTMX5000 MIB File DTMX5000 IP Gateway
4–24 Rev. 1
4.2.6.6 Maximum Rate
MIB Object: cbStaticUserMaxRate
OID: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).
efdata(6247).spectracast(3).DTMX5000(1).cbConfig(2).
cbConfigSTUTable(5).
cbStaticUserTable(1).cbStaticUserEntry(1).cbStaticUserMaxRate(6)
Description: A QoS parameter that specifies the maximum bandwidth allocated for
the static user.
Data Types: INTEGER
Access: Read-write
4.2.6.7 Procedure for Adding a New Static User
Note: This procedure provides the basics for adding a new static user.
Set: 1.3.6.1.4.1.enterprises(2540).efdata(6247).spectracast(3).DTMX5000(1).cbConfig(5).
cbConfigSTUTable(1).cbStaticUserTable(1).cbStaticUserEntry(1).cbStaticUserIP
to: cbStaticUserIP
Where: cbStaticUserIP is the IP address of the new static user.
Set: cbStaticUserMask, cbStaticUserGroup, cbStaticUserMAC, and
cbStaticUserMinRateRate and cbStaticUserMaxRate to the desired values, as follows:
cbStaticUserMask =
1.3.6.1.4.1.enterprises(2540).efdata(6247).spectracast(3).DTMX5000(1).cbConfig(5).
cbConfigSTUTable(1).cbStaticUserTable(1).cbStaticUserEntry(2).cbStaticUserIP
Note: For this parameter, use 255.255.255.255 if static user is not a network.
cbStaticUserGroup =
1.3.6.1.4.1.enterprises(2540).efdata(6247).spectracast(3).DTMX5000(1).cbConfig(5).
cbConfigSTUTable(1).cbStaticUserTable(1).cbStaticUserEntry(3).cbStaticUserIP
Note: Be careful to first create the desired group, if using more than one group ( and more than
12 PIDs).
cbStaticUserMAC =
1.3.6.1.4.1.enterprises(2540).efdata(6247).spectracast(3).DTMX5000(1).cbConfig(5).
cbConfigSTUTable(1).cbStaticUserTable(1).cbStaticUserEntry(4).cbStaticUserIP
cbStaticUserMinRate =
1.3.6.1.4.1.enterprises(2540).efdata(6247).spectracast(3).DTMX5000(1).cbConfig(5).
cbConfigSTUTable(1).cbStaticUserTable(1).cbStaticUserEntry(5).cbStaticUserIP
cbStaticUserMaxRate =
1.3.6.1.4.1.enterprises(2540).efdata(6247).spectracast(3).DTMX5000(1).cbConfig(5).
cbConfigSTUTable(1).cbStaticUserTable(1).cbStaticUserEntry(6).cbStaticUserIP
To delete a group, proceed as follows:
