Central Configuration Unit DTMX5000 IP Gateway
Rev. 1 B-27
The table below describes the color and icon for each event category:
Color Code Icon Category Example
Black ! Normal routine events. User xxx is connected to the
Gateway.
Blue " Infrequent events Restarting the Gateway
Red # Warning, error messages CCU failed to connect to the
Gateway
Pink ! Error messages Routing is not available
Note: When an event is added to the log, the time of the event is also recorded
The events log can store up to 10,000 events, after which it overwrites the oldest
entry, and then the second oldest entry, and so on. When a new event occurs, the
automatic scrolling feature automatically scrolls to the new entry. The CCU
operator can configure the events log to activate/deactivate the automatic
scrolling feature.
To activate automatic scrolling, proceed as follows:
1. Either click the Auto Scroll button in the toolbar (the button appears
selected),
or
Check the Auto Scroll feature in the Viewmenu.
2. The automatic scrolling feature is activated. The events log
automatically scrolls down to a new event entry each time it occurs.
To deactivate automatic scrolling, proceed as follows:
1. Either click the Auto Scroll button in the menu bar (the button appears
deselected),
or
Uncheck the Auto Scroll feature in the View menu.
The automatic scrolling feature is deactivated. The feature is useful if
the CCU operator is reviewing events and does not want the events log to
move automatically to the latest event entry
B.12.2 The CCU Logfile Mechanism
The CCU Logfile Mechanism records to a disk file a copy of the events log that
appears in the main CCU window. This file, called “logfile 000.txt”, is located
in the default CCU directory (C:\Program Files\CCU).
Logfile size is limited to 10 megabytes of disk space. Up to 15 logfiles may be
stored in the CCU directory.
