Specifications DTMX5000 IP Gateway
A–2 Rev. 1
Table A-1. Gateway Specification
Parameters Specifications
Accounting Per IP, Bytes and packets reporting
CE Safety – EN60950
Emissions – EN55022 Class A
Susceptibility – EN50082-1 (1997)
Chassis 19-inch (48.26 cm) rack mountable, 4U height
CPU Intel Pentium 3

(450 MHz)
Craft Interface Interface: Serial EIA-232
Baud Rate: 9600
Information Bit/s: 8
Parity:
None
Stop Bit/s: 1
Compatible: VT100 Terminal
Application: Telnet
Encryption DES based 56 bit keys
FCC Standard 47, CFR Part 15, Subpart B
Format DVB/MPEG2 Transport Stream
Input Interface Transportation input –10/100 BaseT (auto-detect)
Control and Management Input – 10/100 BaseT (auto-detect)
IP Table size Up to 10,000 IPs for unicast or multicast streams
Mapping EN 301 192
Data Streaming
Multiprotocol Encapsulation (MPE)
Monitor and Control SNMP based through LAN interface
Monitoring Features Elaborate statistics, Memory, CPU and total bandwidth usage
Multicast Authorization DES scrambling based – 56 bit
Number of PIDs 8192
Number of Users 10,000 maximum
Operating System Real time operating system – PSOS
Output Interface Parallel LVDS and Serial ASI (Simultaneously)
Power 65 to 250 VAC, 50 to 60 Hz, < 200W
Protocols IP for Unicast and Multicast
QoS Settings per IP address or groups, unlimited levels: Permissive or
Restrictive modes
Software Upgrades TFTP Based, to hard drive
Temperature:
Operating
Storage 0 to +45
°
C (32 to 113
°
F) Humidity 10% to 80%
–20 to –70
°
C ( –4 to –94
°
F) Humidity 10% to 90%
Transfer Rate See Figure A-1.
Weight 15 kg (7 lbs)
