DTMX5000 MIB File DTMX5000 IP Gateway
4–36 Rev. 1
4.2.10 Client Data Flow Statistics Table
The data flow statistics information is stored in the Gateway in a table containing the
following columns:
•
Client IP address.
•
Time stamp of the packet sent to the client.
•
Start time stamp.
•
Total IP packets sent to the client.
•
Average byte per second sent to the client in the last second.
•
Number of packets for the client that were discarded.
•
Total kbytes transmitted to the client.
Note: The index of the Table (its first column) is the client IP address.
Each information object can be accessed by means of two methods:
By row (single client method) The information is retrieved for a client whose IP address is a
set in the cbClientIP object. Each NEXT command will re-
trieve the next statistics object for the client.
By Column (table method) The information is retrieved by information type. Each NEXT
command will retrieve the information object of the next
client. This identifies the first parameter as the client's IP ad-
dress, then the stamp, and so on.
4.2.10.1 Data Flow Statistics Single Client Method
Data Flow Statistics Single Client Method consists of the following:
•
Client IP Address
•
Client Connection Time
•
Kbytes Transmitted to the Client
•
Number of Packets Transmitted to the Client
•
Average Speed of Transmission to the Client
•
Number of Packets Transmitted to the Client that were Discarded
•
Reset Statistics Value for the Client
•
Encryption Enable/Disable
