Central Configuration Unit

DTMX5000 IP Gateway

B-22

Rev. 1

B.10

Configuring the CCU to the Proxy Server

The Proxy Server relays requested information to a client from the Internet or
from its own cache. Each CCU is configured to a specific Proxy Server.

To specify the Proxy Server’s properties, proceed as follows

1. Either click the System Parameters button,

Or

Select System Parameters from the Configuration menu. The System
Parameters window opens.

2. Click the + beside the Proxy Server folder. The Proxy Server folder

expands to reveal a sub-tree level containing the names of the Proxy
Servers on the system, as shown in the following example:
