IEEE/RS232 Configuration and Remote Programming SG Series Programming
3-2 M550129-03 Rev K
Figure 3-2. SG Unit with GPIB/RS232 Option
1 – RS232 (RJ-type 6P6C) connector
2 – Configuration Switch (may be 8-pin or 4-pin) - for correct settings see
Section 3.3.1
3 – IEEE 488.2 GPIB connector
Figure 3-3. SG Unit with RS232 only
1 – RS232 (RJ-type 6P6C) connector
2 – Configuration Switch (may be 8-pin or 4-pin). For correct settings see
Section 3.3.1
