SG Series Programming

SCPI Command Operation

M550129-03 Rev K

6-31

Command

Description

SCPI

:SAVELAST <0|1>

Sets the SAVELAST condition
“0” disables SAVELAST feature
“1” enables SAVELAST feature

N

:SAVELAST?

Returns the status of the Save Last condition

N

:OUTPut

Calibrate Output subsystem

N

:CURRent

Calibrate Output Current subsystem

N

:CALCulate

Calculates the value of the gain and offset for output
current.

N

:DAC

Sets the output of the output current D/A converter.

N

:FIVEPOINT
<1|2|3|4|5>

(Ethernet only) Sets output current value for each
calibration point (1-5)

N

:FIVEPOINT?

(Ethernet only) Returns the entered values for 5-
point calibration.

N

:GAIN

Sets the value of the gain for the output current.

N

:GAIN?

Returns the value of the gain for the output current.

N

:OFFSet

Sets the value of the offset for the output current.

N

:OFFSet?

Returns the value of the offset for the output current.

N

:POINt <1|2>

Sets the current output calibration point
(1 or 2). The actual output current is measured with
an external meter.

N

:VOLTage

Calibrate Output Voltage subsystem

N

:CALCulate

Calculates the value of the gain and offset for output
voltage.

N

:DAC

Sets the output of the output voltage D/A converter.

N

:FIVEPOINT
<1|2|3|4|5>

(Ethernet only) Sets output voltage value for each
calibration point (1-5)

N

:FIVEPOINT?

(Ethernet only) Returns the entered values for 5-
point calibration.

N

:GAIN

Sets the value of the gain for the output voltage.

N

:GAIN?

Returns the value of the gain for the output voltage.

N

:OFFSet

Sets the value of the offset for the output voltage.

N

:OFFSet?

Returns the value of the offset for the output voltage.

N

:POINt <1|2>

Sets the voltage output calibration point
(1 or 2). The actual output voltage is measured with
an external meter.

N

:PROTection

Calibrate Output Voltage Protection subsystem

N

:CALCulate

Calculates the value of the gain and offset for output
overvoltage protection. This takes more than 30
seconds to complete. Use

*ESE 1

and a serial poll

to detect the completed operation.

N

:DAC

Sets the output of the output overvoltage protection
D/A converter.

N

:GAIN

Sets the value of the gain for the output overvoltage
protection.

N

:GAIN?

Returns the value of the gain for the output
overvoltage protection.

N

:OFFSet

Sets the value of the offset for the output overvoltage
protection.

N

:OFFSet?

Returns the value of the offset for the output
overvoltage protection.

N

:UNLock

Sets the non-volatile memory available to store
calibration constants. The access string is “6867”.

:STORe

Stores the calibration constants in non-volatile
memory.

N
