User Manual – Rev M California Instruments
MX15 164

Stay at 122V for 8 seconds before returning to 115V.
Note: Prior to the test, a voltage range change may take place if the power source is set for the
low voltage range. This will cause the EUT to loose power momentarily. If this is not acceptable,
the power source must be left in high range at all times.
The

key (backspace) will terminate the test at any time.
UNDER VOLTAGE
This test will change the output voltage for the selected phase in the following sequence:
For 400Hz and VFREQ:

0V for 7 seconds.

100V for 93 seconds.
For 60Hz only

0V for 2 seconds.

100V for 8 seconds.
The

key (backspace) will terminate the test at any time.
OVER FREQUENCY
This test will change the output frequency in the sequence shown in Table 9-15 before returning
to the steady state frequency.
The

key (backspace) will terminate the test at any time.
Revision D E F F 60Hz only
FREQ Time FREQ Time FREQ TIME FREQ TIME
Seq1 480Hz 5sec. 480Hz 5sec. 480Hz 5sec 61Hz 7sec
Seq2 420Hz 5sec 420Hz 9sec 420Hz 5sec 60.5Hz 8sec
Table 9-15: Abnormal Over Frequency
After this sequence, a 5 second delay will be inserted at the nominal test frequency. The

key
(backspace) will terminate the test at any time.
UNDER FREQUENCY
This test will change the output frequency in the sequence shown in Table 9-16 before returning
to steady state frequency.
The

key (backspace) will terminate the test at any time.
Revision D E F F 60Hz only
FREQ Time FREQ Time FREQ TIME FREQ TIME
Seq1 0 5sec. 0Hz 7sec. 0Hz 7sec 0Hz 7sec
Seq2 375Hz 5sec 380Hz 7sec 380Hz 3sec 59.5Hz 8sec
Table 9-16: Abnormal Under Frequency
After this sequence, a 5 second delay will be inserted at the nominal test frequency. The

key
(backspace) will terminate the test at any time.
