Chapter 26 Configuring IEEE 802.17b Resilient Packet Ring
Verifying and Monitoring RPR-IEEE
•
The show interface rpr-ieee interface-number command (
) displays the following
for an interface:
–
Primary or secondary status (if RI is activated)
–
Active or standby mode (if RI is activated)
–
Up or down (pass-through mode) status
–
Monitoring status and by extension, general protection status
•
The show interface rpr-ieee fairness detail command (
) displays the following for
an interface:
–
Total bandwidth
–
Traffic class configured transmission rates
–
Fairness weight settings for the interface
–
Instances of congestion
•
The show rpr-ieee protection command (
) displays the following for an interface:
–
Station and neighbor interface MAC addresses
–
Protection timer settings
–
Ring protection status
–
Span failures
•
The show rpr-ieee topology detail command (
) displays the following for the ring:
–
Station names and neighbor MAC addresses of all stations on the ring
–
Traffic class configured transmission rates for all stations on the ring
–
Fairness weight settings for all stations on the ring
–
Jumbo frame status (on or off) for all stations on the ring
–
ATD information for all stations on the ring
–
Protection mode for all nodes on the ring
–
Secondary MAC addresses for all stations on the ring
Example 26-3 show interface rpr-ieee 0 Output
router# show interface rpr-ieee 0
RPR-IEEE0 is up, line protocol is up
Hardware is RPR-IEEE Channelized SONET, address is 000e.8312.bcf0 (bia 000e.8312.bcf0)
MTU 1500 bytes, BW 145152 Kbit, DLY 100 usec,
reliability 255/255, txload 105/255, rxload 99/255
Encapsulation: RPR-IEEE,
West Span: loopback not set
East Span: loopback not set
MAC passthrough not set
RI: primary,active peer mac 000e.8312.b870
ARP type: ARPA, ARP Timeout 04:00:00
Last input 00:00:00, output never, output hang never
Last clearing of "show interface" counters never
Input queue: 0/75/0/0 (size/max/drops/flushes); Total output drops: 0
Queueing strategy: fifo
Output queue: 0/40 (size/max)
West Span: 5 minutes output rate 57872638 bits/sec, 25307 packets/sec
