Chapter 24 CE-100T-8 Ethernet Operation
CE-100T-8 Loopback, J1 Path Trace, and SONET/SDH Alarms
CE-100T-8 Loopback, J1 Path Trace, and SONET/SDH Alarms
The CE-100T-8 card supports terminal and facility loopbacks. It also reports SONET/SDH alarms and
transmits and monitors the J1 Path Trace byte in the same manner as OC-N cards. Support for path
termination functions includes:
• H1 and H2 concatenation indication
• C2 signal label
• Bit interleaved parity 3 (BIP-3) generation
• G1 path status indication
• C2 path signal label read/write
• Path level alarms and conditions, including loss of pointer (LOP), unequipped, payload mismatch,
alarm indication signal (AIS) detection, and remote defect indication (RDI)
• J1 path trace for high-order CCAT paths
• J2 path trace for high-order VCAT circuits at the member level
• J2 path trace for low-order VCAT circuits at the member level
• Extended signal label for the low-order paths
