Page 417
24-9
Ethernet Card Software Feature and Configuration Guide, R7.2
Chapter 24 CE-100T-8 Ethernet Operation
Available Circuit Sizes and Combinations
shows VC-3-3v and VC-3-2v circuit size combinations available for the CE-100T-8 on the
ONS 15454 SDH.
A user can combine CCAT high-order, VCAT high-order and VCAT low-order circuits. The CE-100T-8
supports up to eight low-order VCAT circuits.
The available SONET circuit sizes are VT1.5-Xv, where X is the range from 1 to 64. A maximum of four
circuits are available at the largest low-order VCAT SONET circuit size, VT1.5-64v.
details
the maximum density service combinations for SONET.
The available SDH circuit sizes are VC-12-Xv, where X is the range from 1 to 63. A maximum of four
circuits are available at the largest low-order VCAT SDH circuit size, VC-12-63v.
details
the maximum density service combinations for SDH.
3
1
4
None
Table 24-9
VCAT High-Order Circuit Combinations for STS-1-3v and STS-1-2v SONET (continued)
Number of STS-1-3v Circuits
Maximum Number of STS-1-2v Circuits
Table 24-10
VCAT Circuit Combinations for VC-3-3v and VC-3-2v for SDH
Number of VC-3-3v Circuits
Maximum Number of VC-3-2v Circuits
None 4
1
3
2
2
3
1
4
None
Table 24-11
CE-100T-8 Illustrative Service Densities for SONET
Service
Combination
STS-3c or
STS-1-3v
STS-1-2v
STS-1
VT1.5-xV
Number of Active
Service
1
4
0
0
0
4
2
3
1
1
0
5
3
3
0
3
0
6
4
3
0
0
4 (x=1–21)
1
7
5
2
2
2
0
6
6
2
1
4
0
7
7
2
1
1
4 (x=1–21)
8
8
2
0
6
0
8
9
2
0
3
3 (x=1–28)
8
10
2
0
0
6 (x=1–28)
8
11
1
3
3
0
7
12
1
2
5
0
8
13
1
2
2
3 (x=1–28)
8
