Figure 17-9 – Cisco 15327 User Manual
Page 272
17-20
Ethernet Card Software Feature and Configuration Guide, R7.2
Chapter 17 Configuring Cisco Proprietary Resilient Packet Ring
Add an ML-Series Card into a Cisco Proprietary RPR
shows the existing two-node Cisco proprietary RPR with the single STS circuit and span
that will be deleted.
shows the Cisco proprietary RPR after the third node is added with the
two new STS circuits and spans that will be added.
Figure 17-9
Two-Node Cisco Proprietary RPR Before the Addition
SPR 1
POS 1
POS 0
POS 0
POS 1
= STS circuit created on CTC
Adjacent Node 2
Adjacent Node 1
This STS circuit
will be deleted.
New Node
145252
