(Utility Parameters)
d 5 P
^ Units settings
Related parameters
d S P B Frequency units multiplication factor d S P C
d S P F Frequency display resolution
d S P u
d 5 P t
ACC/DEC time units selection
Current units selection
Voltage units selection
Each configurable monitor and parameter display units can be selected by these parameters.
< Frequency units multiplication factor>
d 5 P E setting 0 (OFF)
0.0 1^500
By setting
d S P B
, the motor speed or load equipment speed can be displayed for all parameters
normally displayed in frequency units.
* When
d S P B
is set to a value other than 0, the LED display will be the normal display value x
d S P B .
d S P F setting value Resolution LED display
0
1Hz
: B O
1
0.1Hz :
E0.0
E 0.01Hz IBO.00
d B P t
setting value Resolution LED display
0
1 .
0.1 sec.
0.01 sec.
: 10.0
: 10.00
< Current units selection >
d B P C setting value Function Panel units LED lit
0 % %
1 A None
Note) The values of the monitor items that display current and the values of the following parameters will
change according to the setting value.
Electronic thermal protection level #1, #2
Stall protection level #1, #2
Low current detection level
< Voltage units selection >
b H r 1 t H r - E DC injection current d b C
5 t L 1 B t L E Overtorque trip level O t L
L L P E
d B P u setting value Function Panel units LED lit
0 % %
1 V None
Note) Only the voltage monitor values will change according to this setting. The values of parameters that
are set in voltage units will always be displayed in V.
-
