(3) Status alarms
Alarm characters and the frequency setting may be alternately displayed on the LED in standard
monitor mode. The following four types of characters may be displayed.
C .... When current exceeding the overcurrent stall level flows.
P .... When voltage exceeding the overvoltage stall level is generated.
L •— When 50% or more of the overload trip value is reached.
H .... When the temperature reaches the overheat protection alarm setting level.
Several alarms may also be displayed simultaneously. (’ l C’ ” PC’ ’ L P C ’ )
The alarms will automatically go out when the alarm condition is removed.
(4) Trip information
The standard monitor mode trip display will be entered immediately when a trip occurs.
Display Explanation
OC ; Overcurrent during acceleration
D C S Overcurrent during deceleration
D C S Overcurrent during constant-speed run
D C I P DC section overcurrent during acceieration
D C S P DC section overcurrent during deceleration
D C 3 P DC section overcurrent during constant speed run
D C L Load-end short circuit (output terminal check) trip during start-up
OCR / U-phase short circuit
D C R S V-phase short circuit
D C P 3 W-phase short circuit
D P 1 Overvoltage during acceleration
D P S Overvoitage during deceleration
D P 3 Overvoltage during constant-speed run
D L I n Inverter overload trip
D t n t Motor overload trip
D C r Dynamic braking resistor overcurrent trip
D L r Dynamic braking resistor overload trip
D H Overheat trip
E Emergency stop
E B P 1 EEPROM fault (write error)
E E P S Initial read fault
E r r S RAM fault
E r 3 ROM fault
E t ~ r R CPU error trip
E r r 5 Communication run command interruption error
E r - r E Gate array fault
E r - r l Output current detector fault
E r r B Option PCS fault trip
U C Low-current operating condition trip
U P 1 Undervoltage trip (main circuit)
Oh Overtorque trip
E F l o i E F S Earth-fauit trip
E t n Auto-tuning error
E t U P Inverter typeform error (Special error, refer to page 42.)
n E r r No error (Refer to past trip display on page 35.)
The inverter status at the time of the saved trips (trips that previously occurred) can also be read.
(Refer to Status monitor mode on page 35.)
