GF-114

MODBUS

Communication

Chapter 2

OMM-0035_0C

USER MANUAL

Standard Register Assignments

Page

38 of 200 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 • Ph.: 800-526-0288 05/18/12

Table 2-4: ACS Standard Input Register Address Mapping (Cont.)

Modbus Data

Address

Decimal (Hex)

Menu Item

Units and Range

Default/

Comments

39 (0x0027)

Boiler 15 Status

(Net Boiler 15)

119 = Not On-Line

120 = On-Line But Not Fired

1–40 = Fired & Sequence

121 = On-Line But Disabled

122 = On-Line But Faulted

40 (0x0028)

Boiler 16 Status

(Net Boiler 16)

Same As Above

41 (0x0029)

Boiler 17 Status

(Net Boiler 17)

Same As Above

42 (0x002A)

Boiler 18 Status

(Net Boiler 18)

Same As Above

43 (0x002B)

Boiler 19 Status

(Net Boiler 19)

Same As Above

44 (0x002C)

Boiler 20 Status

(Net Boiler 20)

Same As Above

45 (0x002D)

Boiler 21 Status

(Net Boiler 21)

Same As Above

46 (0x002E)

Boiler 22 Status

(Net Boiler 22)

Same As Above

47 (0x002F)

Boiler 23 Status

(Net Boiler 23)

Same As Above

48 (0x0030)

Boiler 24 Status

(Net Boiler 24)

Same As Above

49 (0x0031)

Boiler 25 Status

(Net Boiler 25)

Same As Above

50 (0x0032)

Boiler 26 Status

(Net Boiler 26)

Same As Above

51 (0x0033)

Boiler 27 Status

(Net Boiler 27)

Same As Above

52 (0x0034)

Boiler 28 Status

(Net Boiler 28)

Same As Above

53 (0x0035)

Boiler 29 Status

(Net Boiler 29)

Same As Above

54 (0x0036)

Boiler 30 Status

(Net Boiler 30)

Same As Above
