GF-114

MODBUS

Communication

Chapter 2

OMM-0035_0C

USER MANUAL

Standard Register Assignments

Page

22 of 200 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 • Ph.: 800-526-0288 05/18/12

Table 2-3: BMS/BMS II Standard Input Register Address Mapping (Continued)

Modbus Data

Address

Dec. (Hex)

Menu Item

Units and Range

Comments

17 (0x0011)

Boiler 1 Status

(PWM Boiler 1)

119 = Not On-Line

120 = On-Line But Not

Fired

1–40 = Fired & Sequence

Boilers 1 - 8 are

referred to as the

Legacy (PWM)

Boilers.(BMS Only)

18 (0x0012)

Boiler 2 Status

(PWM Boiler 2)

(Same As Above)

(Same As Above)

(BMS Only)

19 (0x0013)

Boiler 3 Status

(PWM Boiler 3)

(Same As Above)

(Same As Above)

(BMS Only)

20 (0x0014)

Boiler 4 Status

(PWM Boiler 4)

(Same As Above)

(Same As Above)

(BMS Only)

21 (0x0015)

Boiler 5 Status

(PWM Boiler 5)

(Same As Above)

(Same As Above)

(BMS Only)

22 (0x0016)

Boiler 6 Status

(PWM Boiler 6)

(Same As Above)

(Same As Above)

(BMS Only)

23 (0x0017)

Boiler 7 Status

(PWM Boiler 7)

(Same As Above)

(Same As Above)

(BMS Only)

24 (0x0018)

Boiler 8 Status

(PWM Boiler 8)

(Same As Above)

(Same As Above)

(BMS Only)

25 (0x0019)

Boiler 9 Status (BMS)

(Net Boiler 1)

Boiler 1 Status (BMS II)

119 = Not On-Line

120 = On-Line But Not

Fired

1–40 = Fired & Sequence

121 = On-Line But

Disabled

122 = On-Line But

Faulted

Boilers 9 - 32 are the

Network Boilers.

BMS II has only

Network Boilers,

therefore Net Boiler 1

= Boiler 1, etc.

26 (0x001A)

Boiler 10 Status (BMS) (Net Boiler 2)

Boiler 2 Status (BMS II)

Same As Above

27 (0x001B)

Boiler 11 Status (BMS) (Net Boiler 3)

Boiler 3 Status (BMS II)

Same As Above

28 (0x001C)

Boiler 12 Status (BMS) (Net Boiler 4)

Boiler 4 Status (BMS II)

Same As Above

29 (0x001D)

Boiler 13 Status (BMS) (Net Boiler 5)

Boiler 5 Status (BMS II)

Same As Above

30 (0x001E)

Boiler 14 Status (BMS) (Net Boiler 6)

Boiler 6 Status (BMS II)

Same As Above

31 (0x001F)

Boiler 15 Status (BMS) (Net Boiler 7)

Boiler 7 Status (BMS II)

Same As Above

32 (0x0020)

Boiler 16 Status (BMS) (Net Boiler 8)

Boiler 8 Status (BMS II)

Same As Above
