background image

Chapter 2

MODBUS

Communication

GF-114

Standard Register Assignments

USER MANUAL

OMM-0035_0C

05/18/12 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 • Ph: 800-526-0288

Page

23 of 200

Table 2-3: BMS/BMS II Standard Input Register Address Mapping (Continued)

Modbus Data

Address

Decimal (Hex)

Menu Item

Units and Range Comments

33 (0x0021)

Boiler 17 Status (BMS) (Net Boiler 9)

Boiler 9 Status (BMS II)

119 = Not On-Line

120 = On-Line But Not Fired

1–40 = Fired & Sequence

121 = On-Line But Disabled

122 = On-Line But Faulted

34 (0x0022)

Boiler 18 Status (BMS) (Net Boiler

10)

Boiler 10 Status (BMS II)

Same As Above

35 (0x0023)

Boiler 19 Status (BMS) (Net Boiler

11)

Boiler 11 Status (BMS II)

Same As Above

36 (0x0024)

Boiler 20 Status (Net Boiler 12)

Boiler 12 Status (BMS II)

Same As Above

37 (0x0025)

Boiler 21 Status (Net Boiler 13)

Boiler 13 Status (BMS II)

Same As Above

38 (0x0026)

Boiler 22 Status (Net Boiler 14)

Boiler 14 Status (BMS II)

Same As Above

39 (0x0027)

Boiler 23 Status (Net Boiler 15)

Boiler 15 Status (BMS II)

Same As Above

40 (0x0028)

Boiler 24 Status (Net Boiler 16)

Boiler 16 Status (BMS II)

Same As Above

41 (0x0029)

Boiler 25 Status (Net Boiler 17)

Boiler 17 Status (BMS II)

Same As Above

42 (0x002A)

Boiler 26 Status Net Boiler 18)

Boiler 18 Status (BMS II)

Same As Above

43 (0x002B)

Boiler 27 Status (Net Boiler 19)

Boiler 19 Status (BMS II)

Same As Above

44 (0x002C)

Boiler 28 Status (Net Boiler 20)

Boiler 20 Status (BMS II)

Same As Above

45 (0x002D)

Boiler 29 Status (Net Boiler 21)

Boiler 21 Status (BMS II)

Same As Above

46 (0x002E)

Boiler 30 Status (Net Boiler 22)

Boiler 22 Status (BMS II)

Same As Above
