STEERING-HYDROGEAR
64
20. Inspect the bearings. If they are worn or rough,
carefully drive the inner bearing out of the upper
housing using a pin punch and hammer.
See Figure 6A.49.
21. Drive the outer bearing out of the upper housing
using a pin or brass punch and hammer.
See Figure 6A.50.
22. Thoroughly clean and degrease all parts.
23. Inspect all parts for signs of wear or damage.
NOTE: If the part has signs of wear or damage;
discard the part.
NOTE: If the two bushings in the bottom of lower
gear box housing are worn, replace the lower
housing and press in two new bushings.
To assemble the steering gear box:
1. Put a dab of 737-0300A Durina TM grease into
each of the bushings in the lower housing.
See Figure 6A.51.
2. Install both of the bevel gears with the rollers line
with the center of the housing.
See Figure 6A.52.
Figure 6A.49
Drive out the inner bearing
Figure 6A.50
Figure 6A.51
Put a dab of grease in each bushing
Figure 6A.52
Rollers in line with the
center of housing
