ENGINE RELATED PARTS
6
5. Remove the two screws and two nuts that fasten
the seat box cover. See Figure 2.10.
6. Remove the seat box cover.
7. Clamp the fuel line. See Figure 2.11.
8. Remove the fuel line clamp and slide the fuel
line off.
NOTE: The fuel tank has a barbed fitting. Any-
time a fuel line is removed from a barbed fitting it
should be replaced because of the damage
caused to the fuel line liner.
9. Lift the fuel tank out of the seat box.
10. Install the fuel tank by following the above steps
in reverse order.
11. Test run the tractor and check for leaks before
returning to service.
Figure 2.10
Remove these screws
Remove these screws
Seat box
Figure 2.11
Fuel line clamp
Fuel line
