STEERING-HYDROGEAR
56
3. At the bottom of the lever with the cam slot there
is a connector link. Remove the hairpin clip and
push it out of the lever. See Figure 6A.20.
4. Disconnect the steering links on both sides:
4a. Gently pry the link retainer over the master
link. See Figure 6A.21.
5. Remove the transmission dampener cylinder
using two 1/2” wrenches. See Figure 6A.22.
6. Remove the steering shaft by removing the two
clamp bolts in the steering shaft receiver and lift-
ing the shaft out. See Figure 6A.23.
Figure 6A.20
Remove hair pin
clip
Figure 6A.21
Steering link
Retainer
Figure 6A.22
Transmission dampener
Figure 6A.23
Steering shaft
Steering shaft
Receiver
