Technical details
Operating Manual PNOZ s30
1001715-EN-13
69
Relay outputs 750330 751330
Contact fuse protection, external
safety contacts
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Blow-out fuse, quick 6 A 6 A
Blow-out fuse, slow 4 A 4 A
Circuit breaker, 24V AC/DC,
characteristic B/C
4 A 4 A
Contact fuse protection, external
auxiliary contacts
Blow-out fuse, quick 6 A 6 A
Blow-out fuse, slow 4 A 4 A
Circuit breaker, 24 V AC/DC,
characteristic B/C
4 A 4 A
Conventional thermal current 4,0 A 4,0 A
Contact material AgCuNi + 0,2 µm Au AgCuNi + 0,2 µm Au
Times 750330 751330
Switch-on delay
With automatic reset typ. 15 ms 15 ms
With automatic reset max. 50 ms 50 ms
With automatic reset after power
on typ.
3.920 ms 3.920 ms
With automatic reset after power
on max.
4 s 4 s
With manual reset typ. 40 ms 40 ms
With manual reset max. 100 ms 100 ms
Delay-on de-energisation
With power failure typ. UB 240 V 100 ms 100 ms
With power failure max. UB 240
V
150 ms 150 ms
After safety function is triggered
typ.
8 ms 8 ms
After safety function is triggered
max.
15 ms 15 ms
Recovery time at max. switching
frequency 1/s
After power failure 4 s 4 s
After safety function is triggered 1 s 1 s
Reaction time after limit value is
exceeded
1/f_ist + 16 ms 1/f_ist + 16 ms
Waiting period with a monitored re-
set
With rising edge 30 ms 30 ms
With falling edge 30 ms 30 ms
Min. start pulse duration with a
monitored reset
With rising edge 30 ms 30 ms
With falling edge 30 ms 30 ms
Supply interruption before de-ener-
gisation
20 ms 20 ms
