Page 19: Speed configuration
Function description
Operating Manual PNOZ s30
1001715-EN-13
19
Timing diagram for speed monitoring
t
F2
Delay time (tv)
Rel. 1
Delay effect:
On Off
t
t
Delayed (+filtered)
On
Off
Off
Reset mode monitored/
On
Off
Rel. 1
Feedback loop
t
t
t
Example: Rel. 1
Switch-on
delay
Switch-off
delay
Too short
Start
pulse duration
Too short
Too short
v
Hys. F2
vmax (F2)
vmax (F2) - Hys. F2
0
Configuration in the example:
}
Switch function: F2
}
Assigned output: Rel. 1
}
Delay effect on outputs: On + Off
}
Reset mode: Monitored /
Speed configuration
The speed monitor is configured using the rotary knob on the device.
Up to 16 parameter sets (P0 ... P15), each with a max. of 9 switch functions (F1 ... F9) can
be configured to monitor various operating modes, for example.
One of the 16 parameter sets is selected via 4 select inputs SEL1 (Y10), SEL2 (Y11), SEL4
(Y12), SEL8 (Y13).
4.3.1
4.4
