Pilz PNOZ s30 24-240VACDC 2 n/o 2 n/c - Manual (Page 50)

Commissioning
Operating Manual PNOZ s30
1001715-EN-13
50
Level
Indication
on the display
Description Settings
3 Track AB fmax
Default:
10 mHz Enter max. frequency of the en-
coder on tracks A and B
Important:
The frequency must be less than
or equal to the max. encoder fre-
quency specified in the encoder's
data sheet and less than the max.
speed of the monitored drive.
10 mHz … 1,00 MHz
2 Track Z Settings for track Z
3 Type Z For information only:
Information on configured encoder
type at track Z
3 Track /Z For information only:
Information on the use of the in-
verted track /Z:
No track /Z
or
Inverted (inverted track /Z used)
3 Track Z fmax
Default:
10 mHz Enter max. frequency of the en-
coder on track Z
Important:
The frequency must be less than
the max. encoder frequency speci-
fied in the encoder's data sheet
10 mHz … 1,00 MHz
2 fAB/fZ Ratio
Default:
1,0000 : 1 Enter the ratio of the frequency on
tracks AB "fAB" to the frequency
on track Z "fZ".
Used to check the Z index or for
frequency monitoring on track Z
About
Calculating the frequency ratio:
Enter permanent display: "vz: v:
Position:"
Switch on drive
Read vz and v
Divide v/vz
Enter result as ratio fAB to fZ
0,0001 ... 400.000 : 1
2 Track S Settings for track S (error track)
3 Track S
Default:
Not used Use of track S:
- Not used (track S is not used)
- Evaluation (track S is used) - Not used
- Evaluation
