Operation
Operating Manual PNOZ s30
1001715-EN-13
65
Error
no. Error message Description Remedy
10260 Ini Signal /A
Not permitted Invalid signal at track
/A
-Ensure that the encoders are
configured correctly
-Ensure that the wiring is correct
10261 Ini Signal /B
Not permitted Invalid signal at track
/B
-Ensure that the encoders are
configured correctly
-Ensure that the wiring is correct
10262 Ini Signal A
invalid The signal at track A
is outside the permit-
ted voltage range
-Ensure that the encoders are
configured correctly
-Ensure that the wiring is correct
10263 Ini Signal /B
invalid The signal at track B
is outside the permit-
ted voltage range
-Ensure that the encoders are
configured correctly
-Ensure that the wiring is correct
10264 Track S Error
wrong voltage The voltage at track
S is outside of the
permissible range
(e.g. because the en-
coder has detected
an internal error and
signals this via track
S)
-Check supply voltage of the en-
coders
-Ensure that the wiring is correct
-Check configuration of the min.
and max. voltage at track S
"Track S Umax / Umin"
-Ensure that the encoder oper-
ates correctly
10266 Stuck at High
Track Z or /Z A high signal is al-
ways present at track
Z or /Z.
-Ensure that the encoders are
configured correctly
-Ensure that the encoder oper-
ates correctly
-Ensure that there is no short
circuit in the wiring
10267 Stuck at Low
Track Z or /Z A low signal is al-
ways present at track
Z or /Z.
-Ensure that the encoders are
configured correctly
-Ensure that the encoder oper-
ates correctly
-Ensure that there is no short
circuit in the wiring
10268 Signal error
Track A or B No feasible signal at
the tracks AB
-Ensure that the encoders are
configured correctly
-Ensure that the encoder oper-
ates correctly
-Ensure that the wiring is correct
-Check supply voltage.
10269 Signal error
Track /A or /B No feasible signal at
the tracks /A/B
-Ensure that the encoders are
configured correctly
-Ensure that the encoder oper-
ates correctly
-Ensure that the wiring is correct
-Check supply voltage.
