Operation
Operating Manual PNOZ s30
1001715-EN-13
62
Error
no. Error message Description Remedy
7000 Select Input
not 1 from 4 ! A parameter set oth-
er than P1, P2, P4 or
P8 is selected in
mode "1 from 4".
- Select a longer delay time for
the select inputs in order to filter
out invalid signals resulting from
contact bounce or an intermedi-
ate state
10241 Stuck at High
Track A or /A A high signal is al-
ways present at track
A or /A.
-Ensure that the encoders are
configured correctly
-Ensure that the encoder oper-
ates correctly
-Ensure that there is no short
circuit in the wiring
10242 Stuck at Low
Track A or /A A low signal is al-
ways present at track
A or /A.
-Ensure that the encoders are
configured correctly
-Ensure that the encoder oper-
ates correctly
-Ensure that there is no short
circuit in the wiring
10243 Stuck at High
Track B or /B A high signal is al-
ways present at track
B or /B.
-Ensure that the encoders are
configured correctly
-Ensure that the encoder oper-
ates correctly
-Ensure that there is no short
circuit in the wiring
10244 Stuck at Low
Track B or /B A low signal is al-
ways present at track
B or /B.
-Ensure that the encoders are
configured correctly
-Ensure that the encoder oper-
ates correctly
-Ensure that there is no short
circuit in the wiring
10245 Signal Offset
Track A The signal at track A
has a DC offset
-Ensure that the encoders are
configured correctly
-Ensure that the encoder oper-
ates correctly
-Ensure that the wiring is correct
10246 Signal Offset
Track /A The signal at track /A
has a DC offset
-Ensure that the encoders are
configured correctly
-Ensure that the encoder oper-
ates correctly
-Ensure that the wiring is correct
10247 Signal Offset
Track B The signal at track B
has a DC offset
-Ensure that the encoders are
configured correctly
-Ensure that the encoder oper-
ates correctly
-Ensure that the wiring is correct
