Commissioning
Operating Manual PNOZ s30
1001715-EN-13
49
Level
Indication
on the display
Description Settings
Rotary encoder + pnp proximity
switch
TTL + pnp proximity switch *
- TTL diff. (A, /A, B, /B), Z Freq Inipnp
(Z)
- TTL single (A, B), Z Freq Inipnp (Z)
HTL + pnp proximity switch *
- HTL diff. (A, /A, B, /B), Z Freq Inipnp
(Z)
- HTL single (A, B), Z Freq Ini pnp (Z)
sin/cos 1 Vss + pnp proximity switch
*
- sin /cos 1 Vss (A, /A, B, /B), Z Freq In-
ipnp (Z)
Hiperface + pnp proximity switch *
- Hiperface (A, /A, B, /B), Z Freq Inipnp
(Z)
* Alternatively, a track from an HTL en-
coder can also be used instead of a pnp
proximity switch
The configuration is the same as with
the pnp proximity switch as Z-frequency
monitoring.
2 Track AB Settings for tracks A and B
3 Type AB For information only:
Information on configured encoder
type on tracks A and B
3 Track /A/B For information only:
Information on the use of the in-
verted tracks /A and /B:
No track /A /B
or
Inverted (inverted tracks /A and /B
used)
or
U
ref
external (e.g. "Hiperface" en-
coder type)
3 AB Direction
Default:
Normal Select direction for tracks A and B
Information:
This function is used to display a
forward movement as positive line-
ar/rotational speed, irrespective of
the installation of the rotary encod-
er.
- Normal
- Inverted
