Function description
Operating Manual PNOZ s30
1001715-EN-13
20
The switch functions are monitored simultaneously.
Each of a switch function's 16 parameters can be configured as
} Standstill limit
} Speed limit
} Upper or lower limit of speed range
} Right-hand direction monitoring
} Left-hand direction monitoring
} Position monitoring 1 to 4 with width of position window 1 to 4
Exactly one switch function can be assigned to each output. The same switch function can
be assigned to several outputs. With range monitoring, a range is assigned to an output
(F2-F3, F4-F5, F6-F7 or F8-F9).
A switch delay and start mode can be configured for each output.
If only one parameter set is used, configure the mode "Select inputs: None". The select in-
puts will then be ignored.
Information
2 basic configurations are available for standard applications, for simple
configuration within the display menu. A basic configuration contains limited
menu functions adapted for standard applications, with partly pre-defined
parameters. Further information about basic configurations can be found in
this chapter, under "Basic configuration".
Example configuration:
2 parameter sets for 2 operating modes are configured:
} Set-up: P1
} Automatic mode: P2
The parameter set P1 is used to monitor a reduced speed.
The parameter set P2, "Automatic mode", is selected for speed monitoring (selection via
the select inputs, see next chapter "Select inputs").
The following switch functions are configured for the parameter set P1:
} F1: Standstill 2 Hz
} F2: Overspeed: 50 Hz
} F3: Warning threshold: 50 Hz
The following switch functions are configured for the parameter set P2:
} F1: Standstill 2 Hz
} F2: Overspeed: 3000 Hz
} F3: Warning threshold: 2800 Hz
The following outputs are assigned to the switch functions:
} F1: Relay output Rel. 1
} F2: Relay output Rel. 2
} F3: Semiconductor output Out 1
