Commissioning
Operating Manual PNOZ s30
1001715-EN-13
47
Settings
Level
Indication
on the display
Description Settings
1 Permanent display
Default:
H : Min : Sec (system
time)
v (current speed of
track AB)
Position
Permanent display
Current values and information re-
garding configuration are dis-
played.
You can change the permanent
display on the display
Display combinations:
- vz (current speed of track Z)
- v (current speed of track AB)
- Position
- Switch functions F1 ... F9
- v (current speed of track AB)
- Position
- Line 1/2: F1/F2, F3/F2, F5/F4, F7/F6
or F9/F8
(parameters selected via select inputs).
v (current speed of track AB)
- H : Min : Sec (system time:)
- v (current speed of track AB)
- Position
1 Displ. Units
Speed: Dist:
Default:
Hz pulse Select unit of speed and distance
(position).
Speed (rotational speed) - Pos. (dis-
tance/position)
Hz Imp (pulse)
Hz Edg (edge)
m/s m
m/min m
m/h m
rps rot
rpm rot
1 Conversion
Default:
1Hz =
1 Imp / s Unit conversion.
Enter ratio of unit to pulses. Display
1 Hz = 1 Imp/s
1 Hz = 4 Edg/s
1 m = x Imp (x = 1 ... 10.000.000 Imp)
1 rot = x Imp (x = 1 ... 10.000.000 Imp)
1 Encoder
Settings Create encoder configuration for
the tracks A,
/A, B, /B, Z, /Z, S
6.2.6.4
