Commissioning
Operating Manual PNOZ s30
1001715-EN-13
48
Level
Indication
on the display
Description Settings
2 Encoder
Default:
Undefined Select pre-defined encoder types
for the tracks A, B and Z:
Proximity switch
Rotary encoder
- with and without inverted signals
- with or without Z index (0 index)
- with proximity switch at track Z
Note:
If "Undefined" is selected, an error
message is shown when you con-
firm the menu
No encoder selected:
- Undefined
Proximity switch (Ini):
- Initiator A: pnp B: pnp
- Initiator A: npn B: npn
- Initiator A: pnp B: npn
- Initiator A: npn B: pnp
Rotary encoder:
TTL
- TTL differential (A, /A, B, /B)
- TTL single ended (A, B)
TTL with Z index
- TTL diff. Z index (A, /A, B, /B, Z, /Z)
- TTL single Z index (A, B, Z)
HTL
- HTL differential (A, /A, B, /B)
- HTL single ended (A, B)
HTL with Z index
- HTL diff. Z index (A, /A, B, /B, Z, /Z)
- HTL single Z index (A, B, Z)
Sin/Cos 1 Vss
- sin/cos 1 Vss (A, /A, B, /B)
Sin/Cos 1 Vss with Z index
- sin/cos 1 Vss Z Index (A, /A, B, /B, Z,
/Z)
Hiperface
- Hiperface (A, /A, B, /B)
