Commissioning
Operating Manual PNOZ s30
1001715-EN-13
56
Level Menu designation Description Display/Settings
1 Input Module
SW Version
Va.b For internal purposes only
1 Main Unit
SW Version
Va.b For internal purposes only
- Actual Errors Up to 8 errors are displayed.
Repairable errors: Level 2, 3 and 4
(can be rectified by user)
System errors: Level 2 and 3
(internal error, information for Pilz
Service).
The error messages can be hidden
with "ESCAPE".
Repairable error:
Level 2:
1. Line: Seq. No. "Err.:", error number
2.+3. Line: Plain text to describe error
for the user
Level 3:
1. Line: Seq. No. "Repairable"
2. Line: "System Time:"
3. Line: System time when the error oc-
curred
Level 4:
Information for Pilz Service
System errors:
Level 2:
1. Line: Seq. No. "Err.:", error number
2. Line: "System Error"
3. Line: System time when the error oc-
curred
Level 3:
Information for Pilz Service
- Error Faulty
Signal:
A/A B/B Z/Z Error message: Wrong signal at
one or more tracks.
The message
- is continually updated.
- can be ignored temporarily.
- AB frequency
deviation Error message: Frequency differ-
ence between the proximity
switches on tracks A and B
The message
- is continually updated
- can be ignored temporarily
- Chip card
messages
