Operation
Operating Manual PNOZ s30
1001715-EN-13
63
Error
no. Error message Description Remedy
10248 Signal Offset
Track /B The signal at track /B
has a DC offset
-Ensure that the encoders are
configured correctly
-Ensure that the encoder oper-
ates correctly
-Ensure that the wiring is correct
10249 Signal error
AB: Sin2 Cos2 No feasible signal at
the tracks AB
-Ensure that the encoders are
configured correctly
-Ensure that the encoder oper-
ates correctly
-Ensure that the wiring is correct
-Check supply voltage
10250 Difference-
Signal Error No feasible signal at
the tracks A and /A
or B and /B
-Ensure that the encoders are
configured correctly
-Ensure that the encoder oper-
ates correctly
-Ensure that the wiring is correct
-Ensure that there is not too
much interference on the encod-
er signals
10251 Z-Index
missing No index signal at
track Z
-Ensure that the encoders are
configured correctly
-Ensure that the encoder oper-
ates correctly
-Ensure that the wiring is correct
- Check the configuration of the
frequency ratio fAB to fZ
10252 Z index at
wrong posit. No feasible signal at
track Z
-Ensure that the encoders are
configured correctly
-Ensure that the encoder oper-
ates correctly
-Ensure that the wiring is correct
- Check the configuration of the
frequency ratio fAB to fZ
10255 Signal on
inverted track The inverted tracks
carry a voltage signal
Target status: no sig-
nal (not connected)
-Ensure that the encoders are
configured correctly
-Ensure that the wiring is correct
