Operation
Operating Manual PNOZ s30
1001715-EN-13
61
Error
no. Error message Description Remedy
2002 A frequency
> fmax AB The maximum fre-
quency of the prox-
imity switch at track
A was exceeded
-Enter a max. frequency for
"Track AB fmax" that is not ex-
ceeded during normal operation
-Ensure that a suitable proximity
switch is connected
2003 B frequency
> fmax AB The maximum fre-
quency of the prox-
imity switch at track
B was exceeded
-Enter a max. frequency for
"Track AB fmax" that is not ex-
ceeded during normal operation
-Ensure that a suitable proximity
switch is connected
2004 Z frequency
> fmax Z The maximum fre-
quency of the encod-
er at track Z was ex-
ceeded
-Enter a max. frequency for
"Track AB fmax" that is not ex-
ceeded during normal operation
-Ensure that a suitable encoder
is connected
2007 fAB / fZ does
not fit ! The ratio of the AB
frequency does not
match the fAB/fZ ra-
tio
-Change fAB/fZ in the menu
-Ensure that there is no broken
shear pin or slippage
-Ensure that both encoders are
operating correctly
4010 FL K1-K2 of
Extens.Device Feedback loop K1-
K2 of expansion
module open
-Ensure that the feedback loop
is wired correctly
-Ensure that the expansion
module operates correctly
4011 FL K3-K4 of
Extens.Device Feedback loop K3-
K4 of expansion
module open
-Ensure that the feedback loop
is wired correctly
-Ensure that the expansion
module operates correctly
4012 Extension In-
terface open The terminator on the
expansion interface
is not connected
-Connect terminator
-Ensure that the expansion
module operates correctly
5000 Input Device
undefined! No encoder config-
ured (delivery condi-
tion, default values)
-Create the encoder configura-
tion in the "Encoder settings"
menu
5003 Pos. or Dir.
not with Ini Position monitoring
or direction monitor-
ing configured, al-
though "Initiator" is
selected as the en-
coder
-Do not configure direction or
position monitoring
- Select rotary encoder
6000 AB frequency
deviation Frequency difference
between proximity
switches A and B
e.g. due to edge jitter
at standstill over an
extended period
-Reset error via a valid signal
above the standstill limit or with
a falling edge at input S34
(Start)
- Ensure that the proximity
switches operate correctly
