Commissioning
Operating Manual PNOZ s30
1001715-EN-13
53
Advanced settings
Level Menu designation Description Settings
1 Positions
Parameter Settings for position monitoring
functions
2 Position (1 ... 4)
Window width
Default:
1 Imp Enter width of position window for
position monitoring functions 1 ... 4
1 ... 24.900.000 Imp
or the corresponding value in the se-
lected unit
1 Direction
Parameter Settings for direction monitoring
2 (Direct. left
max. right,
Direct. right
max. left)
Default:
0 Imp Enter max. tolerated number of
pulses (or Edg, m, rot) in the
wrong direction.
1 ... 24.900.000 Imp
or the corresponding value in the se-
lected unit
1 Mode
Select Input
Default:
none Setting for using the select inputs - All 16
- 1 from 4
- None
1 Select Input
Delay
Default:
tdI: 0 ms Enter delay time of the select in-
puts Y10 – Y13
Info: The states of the select inputs
are only adopted if they were un-
changed during the set time.
0 ... 30.0 s
1 Function
Hysteresis
2 (F1 ... F9) Function
Hysteresis
Default:
1 % Enter hysteresis for the switch
functions F1 ... F9
(not effective with position and di-
rection monitoring)
0 ... 50 %
1 Output
Delay Setting for the delay effect and de-
lay time for the outputs
2 Delay
Output
(Rel.1 ... Out 4)
Default:
On 0 ms (display
only)
Setting for the delay time effect
and delay time for the respective
output
6.2.6.5
