Commissioning
Operating Manual PNOZ s30
1001715-EN-13
51
Level
Indication
on the display
Description Settings
3 Track S Umax
Default:
6.0 V Enter max. voltage at track S.
If the voltage is > Umax, an error
is displayed and the outputs are
switched off.
0.0 V ... 30.0 V
3 Track S Umin
Default:
2.0 V Enter min. voltage at track S.
If the voltage is < Umin, an error is
displayed and the outputs are
switched off.
0.0 V ... 30.0 V
1 Delay Time
Start-up
Default:
0.00 s Select start-up delay
(The start-up phase of the PNOZ
s30 is extended by this time. The
encoder signals are not evaluated
until after the start-up phase.)
0 ... 600 s
1 Function
Parameter Select function parameter
2 Standstill
v max:
Default:
2.00 Hz Select standstill frequency 10 mHz ... 1.00 MHz
or the corresponding value in the select-
ed unit
2 (F1 … F9)
Parameter Enter parameter for the switch
functions F1 ... F9
3 (F1 ... F9) (P0 ...
P15)
Parameter
Default:
10 mHz
For each switch function F1 ... F9,
16 parameters P0 ... P15 can be
configured.
4 (F1 ... F9) (P0 ...
P15)
Teach v max:
Display:
Current linear/rota-
tional speed
The current linear/rotational speed
is displayed and can be adopted
as a limit value.
4 (F1 ... F9) (P0 …
P15)
v max:
Standstill
"Standstill" is displayed and can
be adopted
Info:
The standstill frequency is select-
ed globally in the menu "Standstill
v max:"
(see above)
4 (F1 ... F9) (P0 …
P15)
v max
2,00 kHz
Select linear/rotational speed limit 10 mHz ... 1.00 MHz
or the corresponding value in the select-
ed unit
