Commissioning
Operating Manual PNOZ s30
1001715-EN-13
45
} Output assignment
– Standstill: Relay output Rel. 1 and semiconductor output Out 1
– Speed: Relay output Rel. 2 and semiconductor output Out 2
} Reset mode
– Rel. 1, Rel. 2 Out 1, Out 2: Automatic reset
} Switch delay
None
} Max. encoder frequency
3.5 kHz
Basic settings for the rotary encoder
Settings for basic configuration 2
Level
Indication
on the display
Description Settings
1 Load Basic Parame-
ter
Encoder:
Default:
Load?
Select the default settings with
which the basic configuration
menu "Rotary encoder" is to be
called:
-
Load: The basic parameters are
loaded. Switches afterwards to the
basic menu "Rotary encoder".
The basic parameters should al-
ways be loaded when commis-
sioning for the first time.
-
Edit: The basic parameters are
not loaded, i.e. all parameters are
retained. The basic menu parame-
ters can be changed within the
permitted boundaries.
-
ESCAPE: Exits the basic menu.
2 Encoder
Default:
TTL
differential Select rotary encoder type -TTL differential (A, /A, B, /B)
-TTL single ended (A, B)
-HTL differential (A, /A, B, /B)
-HTL single ended (A, B)
-sin/cos 1 Vss (A, /A, B, /B)
-Hiperface (A, /A, B, /B)
2 Standstill
Rel.1 Out 1
Default:
100 Hz Enter standstill frequency 10 mHz to 1.00 kHz
2 v max:
Rel.2 Out 2
Default:
5.00 kHz Enter the max. permitted speed 10 mHz to 1.00 MHz
6.2.6.3
