Commissioning
Operating Manual PNOZ s30
1001715-EN-13
55
Information
Level Menu designation Description Display/Settings
1 System Time Time that the device is switched
on
xxx.xxx h
xx min xx s
1 Max. Speed
Track AB Max. measured linear/rotational
speed at tracks A and B
The value can be reset to 0
0 … 4.29 MHz
or the corresponding value in the set
unit
Reset:
Reset: YES?
1 Max. Speed
Track Z Max. measured linear/rotational
speed at track Z
The value can be reset to 0
0 … 4.29 MHz
or the corresponding value in the set unit
Reset:
Reset: YES?
1 Relay (Ctrl, 1, 2)
Cycles Information:
Total number of relay operations
Relay Ctrl (root relay, common 2nd
shutdown route)
Relay 1 (relay output 1: 11-12, 13-
14)
Relay 2 (relay output 2: 21-22, 23-
24)
0 ... 6.000.000 x, > 6.000.000 x
1 CRC of
Configuration Check sum of configuration pa-
rameters
0 ... 65535
1 Error Stack Entries Error stack entries
Up to 20 error stack entries are
displayed
Repairable errors: Level 2, 3 and 4
(can be rectified by user)
System errors: Level 2 and 3
(internal error, information for Pilz
Service).
See section entitled "Error stack
entries"
Repairable error:
Level 2:
1. Line: Seq. No. "Err.:", error number
2.+3. Line: Plain text to describe error
for the user
Level 3:
1. Line: Seq. No. "repairable"
2. Line: "System time:"
3. Line: System time when the error oc-
curred
Level 4:
Information for Pilz Service
System errors:
Level 2:
1. Line: Seq. No. "Err.:", error number
2. Line: "System Error"
3. Line: System time when the error oc-
curred
Level 3:
Information for Pilz Service
6.2.6.6
